Large spot diameter
slit length reach to 14mm
more comprehensive view of the eye condition
Specification:
|
Microscope |
Microscope Type | Converging stereoscope microscope |
| Magnification selection | two steps magnifications | |
| Eyepiece | 10X | |
| Magnification Ratio(Field of view) | 10X(18mm),16X(14.5mm) | |
| Pupillary Adjustment | 50mm ~ 82mm | |
| Diopter Adjustment | +- 5D | |
| Base | Side Shift | 110mm |
| Depth shift | 90mm | |
| Height shift | 30mm | |
| Chin rest | Height Shift | 80mm |
| Fixation Target | Red LED | |
| Illumination system | Slit Width | 0 ~ 14mm Continuous ( at 14mm , slit becomes a circle ) |
| Slit Height | 0 ~ 14mm Continuous | |
| Slit Angle | 0° ~ 180° adjustable | |
| Slit Inclination | 0° ~ 23 ° | |
| Diameter of Light Spot | Ø14mm, Ø10mm , Ø5mm, Ø3mm, Ø2mm, Ø1mm, Ø0.2mm and 1 ~ 14mm Continuous | |
| Filter | Heat Absorption , Grey ,Red-Free , Cobalt Blue | |
| Illumination Bulb | 12v 50w halogen lamp | |
| Power | Input Voltage | 110V / 220V AC |
| Frequency | 50 / 60 HZ | |
| Power Consumption | 68 VA | |
| Weight and Size | Gross Weight | 18kg |
| Dimension | 690mm(L) × 440mm(W) × 420mm (H) |
