General Parameter:
1. 10.4″ high resolution color LED, high brightness, high contrast, wide visual, LED backlight, image clear and exquisite.
2. Double probe sockets: A mode probe: 10MHz, imported probe with fixation light; B mode probe: 10MHz, imported transducer.
3. Preset items
A. System setting (hospital name, mode selection, date, time, format, probe protection time, help, keyboard sound etc. )
B. IOL setting
C. Network setting, DICOM3.0
D. Password setting
E. Software upgrade setting
4. Diplay: B, B/B, 4B, B/A, A; A single-point measurement(under A mode), five-point measurement(under A mode)
5. Gains range: 0–120dB
6. Dynamic range: 30-100dB, visual and adjustable
7. Gray: 256
8. Intelligent TGC adjustment: 8
9. Internal D disk: 4GB, save mass images, reports, move clips, etc.
10. Report function: Print screen, IOL report, patient report with picture, etc.
11. Two USB ports, support for large capacity USB disk (support for document management/software upgrades/one-key storage), and laser printer directly print various image and report.
12. Dual-mode TV output: PAL/NTSC, connecting to thermal printer and ultrasonic working station.
13. DICOM3.0 network port, realizing network transmission easily.
14. Power supply: AC110/230 -15%~+10%(self-adaption supply voltage) 60/50Hz± 1Hz.
15. Net weight.: 8kg
16. Dimension: 400x186x385mm(length x width x height).
A scan parameter:
| Measuring range: | 15-35mm. |
| Measuring accuracy: | ±0.02mm. |
| Measuring parameter: | ACD, LENS, body Length, axial length. |
| Eye mode: | normal/aphakia/dense cataract/PMMA, Acrylic & Silicon for Pseudo Phakic eyes. |
| Measuring Mode: | Contact and Immersion, automatic and manual. |
| Calculation: | std. deviation, average, automatical measuring 8 groups and average, accompany waveform, results correctable. |
| Measurement methods: | A single-point measurement(under A mode); five-point measurement(under A mode). |
| IOL Formula: | SRK-II, SRK-T, BINKHORST,HOLLADAY, HOFFER-Q, HAIGIS, any of two groups can control display. Calculate IOL, DEM, DAM, REEF, etc. And long term save 100 groups of measurement results of A scan. |
| Magnification: | ×1.0,×2.0,x4.0. |
| Display Depth: | 0~36mm , delayed depth: 0–36mm. |
| Measurement Way: | A single point measurement |
B scan parameter:
| Scan mode: | High accuracy stepping motor drive sector scan. |
| Scan Angle: | 53° |
| Display Depth: | 0~88mm(incl.delayed depth) |
| Delayed depth: | 25–32mm |
| Gray: | 256 |
| Frame frequency: | 30frames/s |
| Depth seletion: | 8 |
| Frame correlation: | 4 |
| Edge enhancement: | 4 |
| Compression Curve: | 8 |
| Post-processing: | 8 |
| Eight Pseudo colors: | 8 kinds (incl. B/W) |
| Image storage | 100 frames permanent image storage. |
| Cine loop: | 256 frames,can measure the playback image. |
| Disk | Disk management. |
| General Measurement: | multi-electronic-rule to measure distance, circumference, area(trace method, ellipse method),volume (ellipse method), angle , histogram, profile , stenosis and curvature etc. |
Standard Configuration:
| 1 | Main unit: 1 pc |
| 2 | 10MHz mechanical sector B probe: 1 pc. |
| 3 | 10MHz A probe : 1 pc. |
| 4 | Calibration cup: 1 pc |
| 5 | Network cable: 1pc |
Optional Configuration:
| 1 | Trolley |
| 2 | Ethernet switch |
| 3 | Footswitch |
| 4 | Prager shell for immersion mode |
