1. 7″ TFT LCD monitor
Bigger,better monitor and icon-display menu for easier operation and settings.
2. Motorized joystick
A motorized joystick with auto tracing mode is adopted, so operation is easier.
3. Refractive measurement with Hexagon prism
With high quality of hexagon prism and highly sensitive CCD,it provides unmatched accuracy and reliability.
4. Auto focus function
Just move, it will automatically focus the eye and get the value.
5. Motorized chinrest
Operator can easily adjust the chinrest with switch located on the operator side and enables speedy reading.
6. Tilt Screen
Tilting screen function that allow wide variance of access whether the operator is sitting or standing.
Specifications
|
|
Vertex distance |
0mm, 12mm, 13,75mm |
| Sphere |
-20 ~ +20D (VD=12) 0.125D step |
| Cylinder |
-8 ~ +8D 0.125D step |
| Axis |
0~180°, 1°step |
| Cylinder form |
-, +, ± |
| Pupil distance |
45~85mm,1mm step |
| Minimum pupil size |
Φ2.0mm |
|
|
Radius of curvature |
5.0~10mm ( increment:0.01mm) |
| Corneal power |
33.75-67.50D( when corner equivalent refractive index is 1.337) |
| ( increment selectable from 0.12,0.25D) |
| Corneal astigmatism |
0.0~8.00D ( increment selectable from 0.12,0.25D) |
| Axis |
1~180° (increment:1°) |
| Corneal diameter |
2.0~14.0mm (increment:0.1mm) |
| Memory of data |
10 measure value for each right and left eye |
| Other |
Chart |
Follow-up colorful fogging chart system |
| Display |
7″ TFT LCD |
| Print |
Thermal printer |
| Power supply |
100~240V,50/60HZ |
| Dimensions |
284 x 514 x 465 mm |
| Weight |
20KG |
