Characteristics:
1.Fully stainless steel structure.
2.Hand wheel type of quick-open door structure.
3.Electric or LPG heated
4.Working pressure:0.14-0.16MPa
5.Working temperature: 126℃
6. Double scale indication pressure gauge
7.Easy to operate,safe and reliable.
Technical Data:
| Technical Data | YX-12HM | YX-18HM | YX-24HM |
| sterilizing volume | 12L | 18L | 24L |
| (φ240×200)mm | (φ280×266)mm | (φ280×390)mm | |
| working pressure | 0.14-0.16MPa | ||
| working temperature | 126℃ | ||
| Max. safety pressure | 0.165Mpa | ||
| power | AC220V.50Hz / 2KW | ||
| dimension | 360×360×520 mm | 420×420×550 mm | 420×420×650 mm |
| G. W / N. W | 12/10 KG | 13/11 KG | 15/13 KG |
